LED Par Can Light PC200D

High brightness, high CRI, professional surface lighting.
LED Par Can Light PC200D
LED Par Can Light PC200D
LED Par Can Light PC200D
LED Par Can Light PC200D
Light Source
4x50W COB LEDs dual-color multichips
Light Output
4000Lm, Center brightness ≧ 2800LUX@23.0’ (7m) (15° Full ON)
Beam Angle

PC200D ParameterPC200D Parameter

  • Description
  • Specifications
  • Video
  • FAQS
  • Downloads


  1. 4x50W COB LEDs multichips.
  2. High brightness, high CRI, professional surface lighting.
  3. High-sensitivity sound control, it can capture 10 sound signals per second.
  4. 0-255level linear dimming, the color is more delicate and gorgeous.
  5. Small size, light weight, easy to install.
  6. Automatic identification of master and slave and DMX control.
  7. Mini size, light weight, easy to install.
SOURCE 4x50W  COB LEDs dual-color multichips EFFECTS Independent electronic strobe, effect with variable speed up to 25 Hz
50,000 Hour Average LED Life* Electronic Dimmer: 0-100% linear
*LED life may differ based on a number of variables, including but not limiting to environmental factors, power/voltage, user behavior
(on-off cycling), controls, and dimming.
PHOTOMETRIC DATA Total Lumen Output: 4000Lm 4 touch button
CRI ≥ 93 LED Display
Beam angle:24° DMX XLR IP20 3*0.75mm² In/Out
Illumination: Center brightness ≧ 2800LUX@23.0’ (7m)
(15° Full ON) spot diameter< 2.2M,
PowerCon IP20 3*1.5mm² In/Out
COLOR Color temperature: 2800K/6300K INCLUDED ITEMS DMX XLR IP20 3*0.75mm² In/Out
Physical Features Die-cast aluminum shell , excellent heat dissipation PowerCon IP20 3*1.5mm² In/Out
SIZE / WEIGHT LxWxH: 317x232x309mm (12.5’’ x 9.1’’ x 12.2”) APPROVALS / RATINGS CE pending | CETLus pending | IP20
Weight: 9.9 lbs. (4.5 kg) (including clamps)
ELECTRICAL Rated Voltage:AC 100-240V 50/60Hz
Rated Power:Max Power Consumption 220W
Working temperature:32°F to 104°F (0°C to 40°C)
QDoes LQE Offer Customized Stage Moving Light Solution?
A An experienced R&D team can provide customized digital stage lighting OEM/ODM solution service to meet clients’ unique demands from global markets, such as customized CRI parameter, Ingress protection rating, effect, etc.
QCan I Have a Sample Order for Led DJ Light?
A Sure, sample order are welcome to test and check LQE quality. Mixed samples are acceptable.
QWhat Kind of Certificates You Offer?
A All kinds of certificates could be offered by LQE digital moving light factory, which depends on customer’s required, different pricing plan for different approval.
QWhat Is the Warranty Offered by LQE Lighting?
A LQE lighting offers a comprehensive 1-year warranty and spare parts on its products, giving customers peace of mind and investment protection.
QDoes LQE Offer a Stage Light Design Solution?
A LQE experienced team glad to supply a stage lighting configuration design solution or suggestion for projector who don’t have much experience in lighting design, project, theatre and studio.
QDo You Supply After-Sale Service?
A LQE lighting offers 7x24 hrs systematic SOP customer support with dedicated personnel, ensuring quick and comprehensive assistance for stage lighting needs.
